Fraunhofer-Institut für Elektronenstrahl-Conference / 04. November 2019 - 06. November 2019
pro flex
Roll-to-roll coating of flexible materials
pro flex 2019
Focus 2019: Technology Cross-Over
Veranstaltungsdetails
Kosten
Early-registration fee (valid until August 19, 2019): 375,- €
Regular registration fee: 445,- €
Student registration fee: 99,- € (with valid student card)
Tutorial: 75,- €
Speakers will benefit from a registration free of charge.
Veranstaltungsort
Winterbergstraße 28 | 01277 Dresden, Germany
Datum
04. November 2019 - 06. November 2019
Organisation
Fraunhofer-Institut für Organische Elektronik, Elektronenstrahl- und Plasmatechnik FEP
Reiternavigation
Welcome
After a successful pro flex 2017, we are delighted to announce the date of pro flex 2019 and to invite you to a highly interesting conference!
November 4 – 6, 2019
Roll-to-roll processing of flexible materials by using wet chemical and vacuum coating technologies is a high growth industry with a wide variety of important industrial products like packaging films, solar control window films, batteries, capacitors, touch-screens, flexible OLED lighting and signage, RFIDs, anti-counterfeiting labels, solar cells, future flexible displays, building envelope components, and many more.
From November 5 – 6, 2019, a colorful conference program on current issues in research and practice of roll-to-roll technology awaits you. 2019, this program is complemented for the first time by an afternoon tutorial on roll-to-roll technologies on November 4.
For a deeper insight, we have prepared a list of presentations which were held at the previous pro flex conferences. Furthermore, you may find a review of pro flex 2017 by Dr. Charles Bishop in the Converting Quarterly 1/2018, on page 26.
If you have any questions, please contact proflex@fep.fraunhofer.de
We are looking forward to your participation in pro flex 2019.
Sincerely,
Nicolas Schiller Annett Arnold
Program Chair Conference Administration
Program
Monday, November 4 | AFTERNOON TUTORIAL |
||
| 13.00 – 14.00 | Light Lunch and Registration | |
| 14.00 – 15.30 | Tutorial Session 1 | |
| 15.30 – 16.00 | Coffee Break | |
| 16.00 – 17.00 | Tutorial Session 2 | |
Tuesday, November 5 | DAY 1 |
||
| starting 09.30 | Registration | |
| Session 1 | ||
| 10.30 – 10.35 | Welcome Address Dr. Nicolas Schiller, Fraunhofer FEP |
|
| 10.35 – 10.55 | Materials and surfaces - trends and challenges Dr. Ralf Fellenberg, VDI Technologiezentrum GmbH |
|
| 10.55 – 11.15 | Enhancing the sustainability of flexible packaging in the Circular Economy Vicente Martínez Sanz, AIMPLAS |
|
| 11.15 – 11.35 | Paper based sustainable food packaging Prof. Lorenzo Pastrana, International Iberian Nanotechnology Laboratory |
|
| 11.35 – 11.55 | High temperature processing of ultra thin glass Takayoshi Saitoh, Nippon Electric Glass Co., Ltd. |
|
| 11.55 – 13.25 | Lunch | |
| Session 2 | ||
| 13.25 – 13.45 | [NEW] Quality factors in permeation barrier coatings on flexible polymer webs Dr. John Fahlteich, Fraunhofer FEP |
|
| 13.45 – 14.05 | Flexible electrochromic devices on metal mesh electrodes: from lab samples to R2R pilot production Dmitri Kossakovski, iGlass Technology, Inc. |
|
| 14.05 – 14.25 | A versatile and flexible roll-to-roll vacuum pilot line tailored to industrial needs Louise Samain, CRM Group |
|
| 14.25 – 14.45 | Unique Vacuum R2R Metallized Coloured Films without using Inks or Dyes Prof. Nadir Ahmed, Idvac Ltd. |
|
| 14.45 – 15.30 | Coffee Break | |
| Session 3 | ||
| 15.30 – 15.50 | PET substrates for Flexible Electronic Applications Valentijn von Morgen, DuPont Teijin Films Ltd. |
|
| 15.50 – 16.10 | R2R processes for Wearables/Results of WAFT project Yu Shu, University Oxford |
|
| 16.10 – 16.30 | Gas monitoring for the enhanced control of web treatment and vacuum coating processes Dr. Dermot Monaghan, Gencoa Ltd |
|
| 16.30 – 16.50 | NOVION®: In-line monitoring using a novel vacuum gauge Dr. Klaus Bergner, VACOM Vakuum Komponenten & Messtechnik GmbH |
|
| 16.50 – 17.10 | Trends in monitoring the integrity of transparent conductive coatings Marcus Klein, SURAGUS GmbH |
|
| 17.10 – 17.15 | Closing of Day 1 | |
| 17.30 – 21.30 | Get together and Dinner at Fraunhofer FEP | |
Wednesday, November 6 | DAY 2 |
||
| 09.00 – 12.00 | Registration | |
| Session 4 | ||
| 09.20 – 09.40 | Fast and inline-capable determination of the water vapor transmission rate (WVTR) of barrier webs using hyperspectral imaging (HSI) Dr. Wulf Grählert, Fraunhofer IWS |
|
| 09.40 – 10.00 | A way of ‘Visualization of Force’ Kei Hyodo, Yuasa System Co., Ltd. |
|
| 10.00 – 10.20 | PVD on thin metal foils for battery applications Markus Piwko, Von Ardenne GmbH |
|
| 10.20 – 10.40 | R2R processes in battery production Dr. Stefan Koller, VARTA Micro Innovation GmbH |
|
| 10.40 – 11.10 | Coffee Break | |
| Session 5 | ||
| 11.10 – 11.30 | Ferroelectric Polymer Sensors for Flexible Electronics Dr. Martin Zirkl, Joanneum Research Forschungsgesellschaft mbH |
|
| 11.30 – 11.50 | SmartMesh® – A transparent metal mesh electrode for printed electronics fabricated on industrial scale Dr. Christoph Hunger, Papierfabrik Louisenthal GmbH |
|
| 11.50 – 12.10 | Manufacturing challenges for conformable OLED lighting Dr. Norman Bardsley, Bardsley Consulting |
|
| 12.10 – 12.30 | [NEW] Overcoming specific challenges on transparent OLEDs in Roll-to-Roll manufacturing Dongxiang Wang, Fraunhofer FEP |
|
| 12.30 – 13.30 | Lunch | |
| Session 6 | ||
| 13.30 – 13.50 | Organic Photovoltaics Dr. Martin Pfeiffer, heliatek GmbH |
|
| 13.50 – 14.10 | Wet Roll to Roll improvement in OPV François Allais, ARMOR SAS |
|
| 14.10 – 14.30 | Late-stage customization of organic photovoltaics Dr. Sebastian Meier, OPVIUS GmbH |
|
| 14.30 – 14.40 | Closing Remarks Dr. Nicolas Schiller, Fraunhofer FEP |
|
| 14.45 – 17.00 | Lab Tours | |
| Material Characterization and Quality Control In-line process monitoring and thin film characterization are essential to provide reliable coating materials and high yield processes. This tour provides a sneak peek into the work done at Fraunhofer FEP and her partners. The lab tour includes a live demonstration of mechanical endurance testers for flexible materials including thin film glass as well as a live demonstration of a fast spatially resolved thin film inspection by Hyperspectral imaging (HSI) and laser-based device for ultra-high barrier measurements (HiBarSens) at Fraunhofer IWS. Process monitoring is demonstrated at our web-coater labFlex® 200 using a novel plasma and vacuum monitor developed by VACOM |
||
| Lightweight Engineering Lightweight Engineering is an important field of contemporary research and development. Achievements in this area have a strong effect on various industries like aerospace, automotive/transportation and construction. Lightweight constructions gain presently importance due to the need of energy savings in virtually all sectors of public life. The Fraunhofer institutes at the Campus Dresden Winterbergstraße work in various projects related to this topic. Those projects do not necessarily involve vacuum deposition steps. The Special Topic Tour “Lightweight Engineering” is intended to provide an impression of the variety of technical challenges in Lightweight Engineering which are presently tackled by Fraunhofer Researchers in Dresden. |
||
| Battery Technologies Join the lab tour and visit our battery related labs ranging from deposition over to cell assembly and testing. Use your chance and get in contact with our specialists. |
||
Tutorial
Tutorial on Roll-to-Roll Deposition: Basics, Technologies, Practical Advice, Latest Developments
The aim of the tutorial is to give you an overview of important aspects and technologies of the field of work "roll-to-roll" technologies. The scheduled topics are:
1 Introduction and overview of the tutorial
2 Vacuum Roll-to-Roll coating- what is worth knowing
2.1 Historical perspective
2.2 General setup
2.3 The quest of high vacuum
2.4 The quest of layer adhesion
2.5 The quest of layer stress
2.6 The quest of heat load
3 Types and properties of flexible substrates for vacuum coating
3.1 Polymers
3.2 Flexible glass
3.3 Others (metal foils, textiles)
4 Practical questions for projects in vacuum roll-to roll processes
4.1 Important substrate parameters
4.2 Transport
4.3 Handling in the lab
4.4 How to denote samples
5 Sputter deposition in vacuum web coating
5.1 Methods
5.1.1 Sputtering
5.1.2 Reactive sputtering
5.1.3 Planar or rotatable magnetrons?
5.1.4 Side remark: PECVD
5.2 Markets and application
5.2.1 Transparent conductors
5.2.2 Radiation management coatings
5.2.3 High barriers coatings
5.2.4 Anti-Reflective coatings
5.3 Challenges for future developments
5.4 Special focus of FEP
5.4.1 Deposition processes
5.4.2 coFlex 600 – a pilot tool for advanced R&D projects
6 Evaporation technologies for roll-to-roll web coating
6.1 Principal Set up and and overview
6.2 Thermal evaporation
6.3 Electron beam evaporation
6.4 Evaporation from radiant heated sources
6.5 Evaporation from induction heated sources
6.6 Evaporation: reactive mode
6.7 Plasmaactivated mode
7 R2R OLED manufacturing
8 Electron beam curing – a renewed technology
- to be completed and subject to change -
Accomodation
MOTEL ONE DRESDEN AM ZWINGER
Postplatz 5 | 01067 Dresden, Germany
Phone +49 351 43838-0
Motel One Dresden am Zwinger
Steigenberger Hotel de Saxe
Neumarkt 9 | 01067 Dresden, Germany
Phone +49 351 4386-0
Steigenberger Hotel de Saxe
Sponsors / Exhibitors
Be part of the conference!
Benefits of sponsorship start when you sign up and last until long after the pro flex! Every sponsor is acknowledged during their sponsored event with prominent signage, on the pro flex web site and in all pro flex publications throughout the year. Participate in our Sponsor Program to reinforce your name recognition and demonstrate your commitment to the industry.
Use the chance to take part in our tabletop exhibition if you would like to present your products and services to local and international experts in the roll-to-roll industry.
Ask for sponsorship and exhibition possibilities by email: proflex@fep.fraunhofer.de
See our Sponsorship Options for detailed information:
Sponsors
Platinum Sponsor
 |
AIMCAL Association of International Metallizers, Coaters and Laminators www.aimcal.org |
Silver Sponsors
 |
YUASA SYSTEM CO., LTD. www.yuasa-system.jp |
| Your logo here! | Your company name here! |
Exhibitors
|
YUASA SYSTEM CO., LTD. www.yuasa-system.jp |
 |
robeko GmbH & Co. KG www.robeko.de |
| Your logo here! | Your company name here! |
Program Board
Program Board
 |
|||
| Dr. Nicolas Schiller Program Chair |
|||
 |
 |
 |
 |
| Dr. Matthias Fahland | Dr. John Fahlteich | Dr. Steffen Günther | Dr. Manuela Junghähnel |
 |
 |
 |
 |
| Claus Luber | Dr. Christian May | Steffen Straach | Dr. Michiel Top |
